TEC1-12707

Get ice cold in minutes or heat to boiling by simply reversing the polarity, used for numerous applications, from CPU coolers to alternate power sources, or even for your own custom car drink warmer/cooler. Since they consist primarily of semiconductor material sandwiched between ceramic plates and have no moving parts,. These devices must be used in conjunction with a heat sink to avoid being burned. Each device is fully inspected and tested. Fitted with 6-inch insulated leads.

Connected to a 12-volt power supply, the cell will have a temperature differential between the two sides of about 20 °C (68 °F).

Important: Do not connect the cell to a power supply for more than a few seconds without a heat-sink on the hot side; otherwise, there will be internal overheating and destruction of the Peltier cell.

Specifications

• Model: TEC1-12706
• Size: 40mm x 40mm x 4mm
• Operates : 0~12V DC and 0~4.5A
• Operates Temperature: -30°C to 70°C
• Max power consumption: 60 Watts
• Net weight: 22g
• Color: White
